1. Available Solutions

Linear statics, modal, stress linearization, thermal, coupled thermal-stress, nonlinear statics (contact, material and geometrical), fatigue analysis, linear superpositioning, linear dynamics (time, frequency, and random response)

2. Materials

Isotropic, Elasto-plastic, Orthotropic, Rigid parts and liquid bodies

3. Supported Connections

Bonded, sliding and separating with friction, bolts, virtual connectors, welds (spot, laser, and fillet), rivets, adhesives, joints, and bushing

4. Boundary Conditions

Immovable, sliding, hinge, force, pressure, gravity, thermal, inertial loads, inertia relief, bolt/nut tightening, hydrostatic, bearing, volumetric expansion and shrinkage, distributed and remote mass, and remote loads

5. CAD Connectivity

Reads all common CAD/PLM file formats including: CATIA, NX, PTC/Creo, Inventor, Fusion 360, SOLIDWORKS, JT, STEP, VDA, Parasolid, ACIS, PLMXML, CGR, STL. Direct data integration to Onshape and Teamcenter.

6. Result Types

Contour plots with displacements, stress & strains, deformed shape animation, max/min labels, point probes, XY plots, reaction/contact forces, bolt/nut forces, spot weld forces, frequencies and mode shapes, modal participation factors, safety factors
